SE4500

11.8 mm H x 21.5 mm W x 16.3 mm D8.22 gramsCamera Port on 21 pin ZIF connector752 x 480 pixelsHorizontal: 40°, Vertical: 25°

SE4750 scan engine

11.8 mm H x 21.5 mm W x 16.3 mm D8.22 gramsCamera Port on 21 pin ZIF connectorHorizontal: 48°, Vertical: 36.7°1280 x 960 pixels

SE4850 OEM 1D/2D Scan engine

19.0mm x 38.0mm x 5.0 mm1.41 +/- 0.07 ounces/40 +/- 2 grams27 pin 0.3 mm pitch ZIF connector, MIPI1280 X 800

SE3307 ARRAY IMAGER SCAN ENGINE

D 17 mm H x 30 mm W x 26 mm D0.36 oz./10.2 g31-pin ZIF connector, micro USB 752 x 480 pixelsHD: Horizontal - 40°, Vertical - 25°

SE4710 스캔 엔진

D 8.1 mm H x 22.3 mm W x 13.7 mm 4.8 gramsCamera Port on 27 pin ZIF connectorHorizontal: 42°, Vertical: 28°1280 x 800 pixels

SE4720-SE4770 스캔 엔진

8.1 mm H x 22.3 mm W x 13.7 mm D4.85 g +/- 0.25 gHorizontal: 48°, Vertical: 30° Red LED or Warm-White LED

SE4107 OEM 1D/2D Scan engine

D 11.5 mm H x 22.3 mm W x 13.7 mm D5.5gSerial or USB on 12-pin connectorHorizontal: 44.5°, vertical: 33.5°1280 x 960, rolling shutter

SE2707 스캔 엔진

12.6 mm H × 22.3 mm W × 18.0 mm D 6.2 gramsSSI Control over TTL Serial or USB on 12-pin ZIF connector42.0º horizontal, 28.0º vertical640 X 400
